Rack Milling Cutters
We manufacture various types of Rack Milling Cutters to cut Racks for various applications.
Our Range
| Module |
1M to 8M |
| Diameter |
80mm to 200mm |
| Length |
80mm to 250mm |
| Quality |
Class A & AA |
| Material |
M-35, ASP-2030, ASP-2052, S-590 & S-390 |
Master Gears
We Supply Spur & Helical Master Gears. The Master Gears can be supplied with profile modifications and Tin coating.
Our Range
| Module |
1M to 8M |
| PCD |
Up to 150mm |
| Width |
Face width up to 60mm |
| Quality |
DIN - 3 & DIN - 4 as per DIN 3962 |
| Material |
M2, M-35, ASP-2030 |
Shaving Cutters
We manufacture all type of Shaving Cutters - Conventional, Diagonal, Underpass & Plunge cut with profile modification such as lead and involute crowning. The Shaving Cutters can be supplied with or without coating as per client�s requirements.
Our Range
| Module |
1.25M to 8M |
| PCD |
Up to 275mm |
| Standard |
BS2007-1975 |
| Material |
M2 (F) M3-II & ASP-2023 |
Gear Shaping Cutters
Gear Shaping Cutters both Disc type, Hub type can be made to qualify all standards. We can supply Shaper Cutters with coating.
Our Range
| Module |
1M to 8M |
| PCD |
Up to 150mm |
| Width |
Face width as per requirement |
| Quality |
Class A , & B |
| Standard |
DIN 1829 � 1973 / 1977 |
| Material |
M-35, ASP-2030 |
Hob Cutters
Our Hob Cutters range includes Gear Hobs, Spline Hobs, Serration Hobs, Sprocket Hobs, Timing Belt Pulley Hobs, Ratchet Hobs and Worm Wheel Hobs of all profiles. We supply both bore and shank type Hobs in single & multi starts with straight and helical flute with or without coating.
Our Range
| Module |
0.2M to 20M |
| Diameter |
24mm to 260mm |
| Quality |
AAA, A A, A & B |
| Standard |
DIN, AGMA, BS, GOST etc |
| Material |
ASP-2030, ASP-2052 S-590, S-390 & S-290 M-35 etc. |
Spline Milling Cutters
Single lip and Double lip spline miling cutters are Manufactured to be used on Milling Machine.
Our Range
| Involute Spline |
| Parallel Spline |
